Placa Gigabyte Z690 Aorus Tachyon
- Fabricante: Gigabyte P/N: Z690 AORUS TACHYON EAN: 4719331830380 Código: 61163
441,06 €
(Impuesto incl.) Z590 AORUS TACHYON es el pináculo de la placa base de overclocking completamente diseñada por y para overclockers, que buscan continuamente romper el límite de rendimiento inimaginable. Su diseño VRM especializado, seguimiento de distribución de memoria y botones e interruptores de overclocking integrados permiten a los entusiastas del overclocking liberar todo el potencial del procesador Intel Core de última generación.
- CPU
- LGA1200 package:
- 11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors
- 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors*
- * Limited to processors with 4 MB Intel® Smart Cache, Intel® Celeron® G5xx5 family.
- L3 cache varies with CPU
- (Please refer to "CPU Support List" for more information.)
- Chipset
- Intel® Z590 Express Chipset
- Memory
- 11th Generation Intel® Core™ i9/i7/i5 processors:
- Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
- 10th Generation Intel® Core™ i9/i7 processors:
- Support for DDR4 2933/2666/2400/2133 MHz memory modules
- 10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors:
- Support for DDR4 2666/2400/2133 MHz memory modules
- 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
- Dual channel memory architecture
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for Extreme Memory Profile (XMP) memory modules
- (Please refer "Memory Support List" for more information.)
- Onboard Graphics
- Integrated Graphics Processor-Intel® HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
- * Support for HDMI 2.0 version and HDCP 2.3.
- (Graphics specifications may vary depending on CPU support.)
- Audio
- Realtek® ALC1220-VB codec
- * The back panel line out jack supports DSD audio.
- Support for DTS:X® Ultra
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for S/PDIF Out
- LAN
- Intel® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
- Wireless Communication module
- Intel® Wi-Fi 6E AX210
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.2
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
- * Actual data rate may vary depending on environment and equipment.
- Expansion Slots
- 1 x PCI Express x16 slot, running at x16 (PCIEX16)
- * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
- 1 x PCI Express x16 slot, running at x8 (PCIEX8)
- * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
- (The PCIEX16 and PCIEX8 slots conform to PCI Express 4.0 standard.)*
- * Supported by 11th Generation processors only.
- 1 x PCI Express x16 slot, running at x4 (PCIEX4)
- 1 x PCI Express x16 slot, running at x1 (PCIEX1)
- (The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)
- Multi-Graphics Technology
- Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
- Storage Interface
- CPU:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)*
- * Supported by 11th Generation processors only.
- Chipset:
- 2 x M.2 connectors (Socket 3, M key, type 2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2P_SB)(M2M_SB)
- 6 x SATA 6Gb/s connectors (SATA3 0~5)
- * Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
- Intel® Optane™ Memory Ready
- ASMedia® ASM1061 chip:
- 2 x SATA 6Gb/s connectors (SATA3 6,7), supporting IDE/AHCI mode only
- USB
- Chipset:
- 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 4 x USB 2.0/1.1 ports available through the internal USB headers
- ASMedia® USB 3.2 Gen 2 controller:
- 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
- 1 x USB 3.2 Gen 2 Type-A port (red) onboard
- Chipset+Realtek® USB 3.2 Gen 1 Hub:
- 4 x USB 3.2 Gen 1 ports on the back panel
- Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 2 x 8-pin ATX 12V power connectors
- 1 x CPU fan header
- 1 x water cooling CPU fan header
- 4 x system fan headers
- 2 x system fan/water cooling pump headers
- 2 x addressable LED strip headers
- 2 x RGB LED strip headers
- 3 x M.2 Socket 3 connectors
- 8 x SATA 6Gb/s connectors
- 1 x front panel header
- 1 x front panel audio header
- 1 x USB Type-C® header, with USB 3.2 Gen 2 support
- 1 x USB 3.2 Gen 2 Type-A port (red)
- 1 x USB 3.2 Gen 1 header
- 2 x USB 2.0/1.1 headers
- 1 x noise detection header
- 2 x Thunderbolt™ add-in card connectors
- 1 x Clear CMOS jumper
- 1 x power button (PW_SW)
- 1 x reset button (RST_SW)
- 1 x Clear CMOS button (CMOS_SW)
- 2 x BIOS switches (BIOS_SW)(SB)
- 1 x Cold Reset button (RTY_SW)
- 1 x Protection Mode button (LIMP_MODE)
- 1 x CPU Ratio up button (RATIO_UP)
- 1 x CPU Ratio down button (RATIO_DW)
- 1 x Profile A button (PROFILE_A)
- 1 x Profile B button (PROFILE_B)
- 1 x OC Trigger switch (TGR)
- 1 x LN2 Mode switch (LN2_SW)
- 1 x Enhanced LN2 Mode switch (LN2_OFFSET)
- 1 x Reserved switch (RSV_SW)
- ?All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.
- Back Panel Connectors
- 1 x Q-Flash Plus button
- 1 x OC Ignition button
- 1 x PS/2 keyboard port
- 1 x PS/2 mouse port
- 2 x SMA antenna connectors (2T2R)
- 1 x HDMI port
- 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
- 3 x USB 3.2 Gen 2 Type-A ports (red)
- 4 x USB 3.2 Gen 1 ports
- 1 x RJ-45 port
- 1 x optical S/PDIF Out connector
- 5 x audio jacks
- I/O Controller
- iTE® I/O Controller Chip
- H/W Monitoring
- Voltage detection
- Temperature detection
- Fan speed detection
- Water cooling flow rate detection
- Fan fail warning
- Fan speed control
- * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
- Noise detection
- BIOS
- 2 x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- Support for DualBIOS™
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Unique Features
- Support for APP Center
- * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
- @BIOS
- EasyTune
- Fast Boot
- Game Boost
- RGB Fusion
- Smart Backup
- System Information Viewer
- Support for Q-Flash Plus
- Support for Q-Flash
- Support for Xpress Install
- Bundled Software
- Norton® Internet Security (OEM version)
- cFosSpeed
- Operating System
- Support for Windows 10 64-bit
- Form Factor
- E-ATX Form Factor; 30.5cm x 27cm
-/-
